This page offers ConfigPortal users the opportunity to create and manage marker definitions. As shown in the image below, multiple definitions may be configured. However, only a single one may be active at any given time: Import Marker [ENT 21.1 OG]

Pressing the “+” will allow users to create a new one. User can also edit an existing one by clicking “edit” action from an entry on the list.

Once in the Marker definition page, one can choose a name and label for the marker definition. The list of the segment metadata group is predefined based on ConfigPortal’s connection. Those which are then made available will be visible for selection. Based on the groups choice, users can then map the fields in the group that should be expressed in the marker definition’s title and comment fields.

Field

Description

Marker Name

the name of the marker definition

Marker Label

the label of the marker definition

Segment Metadata Group

all segment list / meta data groups in the system

Segment Marker Title Field

meta data of the meta data group which is mapped to the PPro Marker Title

Segment Marker Comment Field

meta data of the meta data group which is mapped to the PPro Marker Comment

Marker Color

color of the PPro Marker

Marker Type

Marker type in PPro

  • Comment: contains title and comment

  • Chapter: contains title only

  • Segmentation: contains title only
